Discharges and treatment of municipal waste water

Updated: October 12, 2020

Next update: October 13, 2021

Phosphorus discharged annually from wastewater facilities 50 pe or larger

Selected tables and figures from this statistics

About the statistics

The Discharges and treatment of municipal waste water statistic describes different sides of the municipal wastewater sector e.g. fees, self cost, type of wastewater facilities, people connected, compliance with treatment permits and sludge disposal.

Wastewater facility is defined in the Pollution regulation (FOR 2004-06-01 nr 931) as any plant handling wastewater consisting of one or more components: wastewaterpipelines, wastewater treatment plant or a discharge device (unofficial English translation).



Biological oxygen demand (BOD5) and chemical oxygen demand (COD) are parameters which indirectly measure the level of organic material in wastewater. BOD5 measure the amount of oxygen consumed biochemically in water after 5 days (standard test is 20 degrees celcius over 5 days). COD also measure the amount of oxygen consumed, but this time a strongly oxidising agent is added to the water (usually containing sulphur acid and potassiumdicromat (K2Cr2O7)).

COD will normally show a higher level than BOD5, since more organic compounds will be oxidised and degraded by the added chemicals, as compared to a BOD5-test.



Operating costs constitutes the sum of administrative-, management- and maintenance costs. Data is derived from KOSTRA-form number 23: Cost absorption in water-, waste water and waste-sector’.



Contribution margin ratio refers to, in percent, how big a share of the annual wastewater related costs the municipalities actually cover by wastewater fees. Municipalities are not entitled to claim more than actual costs, neither are they obliged to claim full cost coverage.



Wastewater fees, claimed by the municipality, consist of a connection fee and an annual wastewater fee. The connection fee is collected once only - during installation - while the wastewater fee is collected every year.



Capacity and load. The capacity of a treatment plant is the amount of wastewater it is designed to handle, while the load is the amount of wastewater a wastewater plant actually receives. The unit of both capacity and load is provided in population equivalents (pe).



High-grade wastewater treatment plants are those that provide a biological and/or chemical treatment phase. Biological treatment mainly removes readily degradable organic material using microorganisms. The chemical phase involves the addition of various chemicals to remove phosphorus. Certain treatment plants also have with special phases for nitrogen removal. High-grade plants reduce the amounts of phosphorus and other pollutants in the effluent more effectively than mechanical plants.



Full cost ratio reflects the relationship between the income from fees and the fee calculation basis, and includes fund provisions and purchases from funds.



Capital cost consists of the following two costs: Depreciation of earlier annual investments and a calculated interest cost for capital goods.



Municipal wastewater facilities include all wastewater facilities and treatment plants with a capacity of 50 pe or more, also including those with no municipal ownership (for example privately owned). The facilities are generally divided into six groups: direct discharge, mechanical, chemical, biological, chemical-biological, and natural purification processes/other treatment.



Mechanical wastewater treatment plants include sludge separators, screens, strainers, sand traps and sedimentation plants. They remove only the largest particles from the wastewater, thus treatment efficiency in regards to nitrogen and phosphorus is relatively low.



The North Sea Agreements/OSPAR convention refers to the joint declarations made by the countries around the North Sea to reduce inputs of nutrients to this sea-area. One of the targets was to halve the total inputs of nitrogen and phosphorus during the period 1985 to 1995. Since Norway did not reach the nitrogen target by the end of 1995, the national time limit was extended to 2005. The North Sea Agreements applies to the areas south of the 62o N. As for the nutrient reduction targets, only the counties with drainage into the Skagerak and North Sea, from the Swedish boarder to Lindesnes, are bound by the agreement.



North Sea counties entail the following counties: Østfold (01), Akershus (02), Oslo (03), Hedmark (04), Oppland (05), Buskerud (06), Vestfold (07), Telemark (08), Aust-Agder (09) and Vest-Agder (10). Practically all land areas in these counties drain into the Skagerak and North Sea.



Population equivalent (pe) is defined as the amount of oxygen consumed in 5 days when organic material is decomposed in water. When 1 pe is defined as 60 g BOD5, it means that 1 pe will bring in daily the amount of organic material that microorganisms need 60 g of oxygen to decompose within 5 days.



Wastewater treatment plants are generally divided into three main groups according to the type of treatment they provide: mechanical, biological or chemical. Some plants incorporate combinations of these basic types. In addition, combinations of these basic types also exist.



Treatment efficiency refers to the relative change in weight of a particular chemical substance between the measuring points in and out of the wastewater treatment plant. E.g. 30 per cent treatment efficiency means the 30 per cent of the amount going in to the wastewater treatment plant are removed before discharge into the recipient.



Individual wastewater treatment facilities are designed to handle wastewater equivalent to the amount, or composition, of no more than 50 pe (generally, private plants in areas with scattered settlements). Individual wastewater treatment facilities also include those facilities, which until 2000 was named "separate wastewater facilities". Since the term "individual wastewater facilities" comprise a larger population than "separate wastewater facilities", the two cannot readily be compared.



Wastewater facilities without treatment refer to discharges originating from wastewater facilities without treatment, also commonly referred to as direct discharges. The discharge is connected to municipal pipelines, but it doesn't take place any form of treatment.



Annual cost is the sum of operating and capital costs.

Name: Discharges and treatment of municipal waste water

Topic: Nature and the environment

October 13, 2021

Division for Energy, Environmental and Transport Statistics

The figures are mainly published on national and country level, but also in part on municipality level.

The statistics is published annually, normally in October, with a following report relseased in December (based on the same data material; english summary only).

The statistics is reported to EUROSTAT/OECD as part of their Joint Questionnaire on inland waters (JQ-IW).

The datamaterial is saved as text files (long term backup). Revised dataset are also saved temporarily in different Oracle databases with Statistics Norway.

The Norwegian Environment Agency (Miljødirektoratet) have a copy of the same data.

The purpose with the statistics is to give an overview of the status and development in the municipal wastewater sector. Among other things, it provides information about number of wastewater plants, treatment capacity, type of treatment, degree of people connected, sludge disposal, discharges, economical figures in wastewater sector (investments costs and income), together with illustrating, on a municipal level, the relationship between revenues from wastewater fees, annual costs, and wastewater tariff.

Data collection was carried out sporadically in the 1980s, however since 1990 there's been a data collection on an annual basis. First it was administered under the name SSB-avløp, a co-operation between county administrations and Statistics Norway; secondly there was SESAM (1998-2001); thirdly the Municipality-State-Reporting (KOSTRA) (2002-2014), and last by the Norwegian Environment Agency (from 2015).

Important user groups of the wastewater statistics are the different national and regional public administrations/governments, mainly the Ministry of Environment, Norwegian Environment Agency, the different county administrations and municipalities. To various degrees, other potential user groups are science, media, business and industry and NGOs.

All users of the statistics will access new releases from our website at the same time (8 am in the morning on the release day).

The statistics here is constructed based on the same data material as Municipal wastewater.

The statistics is also related to other statistics concerning discharge and pollution of water. The discharge figures of the wastewater sector, together with the similar figures from agriculture, industry and aquaculture, add up to a national account on nitrogen and phosphorous discharges for Norway, the socalled Comprehensive Study on Riverine Inputs and Direct Discharges (RID) (in Norwegian only).

KOSTRA data are collected by Statistics Norway on behalf of the Climate and Pollution Agency with legal basis in the Pollution Control Act. Statistics Norway can make use of the collected data for official statistical purposes with legal basis in the Statistics Act.

The Climate and Pollution Agency collect their data solely with legal basis in the Pollution Control Act (13th Mars, 1981, no. 6).

Council Directive of 21 st May 1991 concerning urban wastewater treatment (91/271/EEC).

All wastewater facilities and treatment plants (complete data collection).

Physical data: Complete collection. All the municipalities are reporting yearly on behalf of more than 2 700 wastewater facilities (approved for 50 population equivalents (pe) or more, reported by the facility) and around 300 000 individual wastewater facilities, the latter most commonly situated in scattered settlements (reported aggregated by the municipality).



Financial data: Complete collection. Annual reporting for all municipalities.

Notably, since 2001, all municipalities have reported their accounts electronically with KOSTRA, and this created, together with the new account scheme, a way of utilizing the accounts as a powerful information source to financial statistics within municipal wastewater sector.

However, by collecting data directly from the municipality’s accounts, information from various organisation structures will not be collected because they are not visible in the account for the municipality. Therefore data for cost absorption since 2006 is collected via KOSTRA questionnaire 23 (Kostnadsdekning i vann, avløps- og avfallssektoren). The data reported must be limited to the instruction for calculation of full cost.

Data is collected electronically once every year. KOSTRA data to Statistics Norway have deadline 15 th of February, while data reported to the Directorate of Environment is due 30th of February.

The electronic forms all contain built-in consistency checks and logical tests. When the data arrive Statistics Norway, they will be checked again, both automatically and manually.

The most updated and detailed theoretical framwork and methodology applied in wastewater statistics is published in Norwegian language only (English summary), see the report Municipal wastewater: Expenditures, investment, municipal fees, discharges, treatment and disposal of sewage sludge. A brief summary of the methodology in English is however presented below here.

Calculation of discharges of phosphorous and nitrogen



Due to the fact that only part of wastewater facilities undertake direct analysis of pollution loads and discharges, some level of estimation and the use of standard factors needs to be applied in the calculations. Thus, total discharge and treatment efficiency figures of nitrogen and phosphorus are in part based on estimations (see below for further details).

The following calculation procedure has been applied to municipal wastewater facilities, capacity of 50 population equivalents (pe) or more:

  1. If information on discharge quantity, expressed as kilogram per year, has been reported, then this information will be used directly.

  2. If no information as specified in point 1 above has been reported, but outflow concentrations and average water quantities have been provided, then discharge quantity is calculated in kilos per year from the following equation:



    Concentration (mg/l) x average water quantity (m 3 /year) / 1000

  3. If neither point 1 nor 2 above can be calculeted, then discharge quantities will be estimated by multiplying the number of people connected to the wastewater facility with a standard factor for average discharge per person and another factor for standard treatment efficiencty. These factors are listed below:
Average discharge per person per day:



1.8 gram (phosphorus)



12 gram (nitrogen)



Standard treatment efficiencies of different types of treatment plants (per cent):

Type of treatment

Phosphorus

Nitrogen

Mechanical

15

15

Chemical

90

20

Biological

30

20

Chemical-biological

95

25

Natural purification processes/other

75

20

Discharge of nitrogen and phosphorous per year at the outlet of wastewater facility can then be estimated from the following equations:



Phosphorous: ((number of persons connected x 1.8 x 365) / 1000) x average treatment efficiency



Nitrogen: ((number of persons connected x 12 x 365) / 1000) x average treatment efficiency




Small wastewater treatment facilities (less than 50 pe), usually individual plants, make use of the same set of standard factors on average discharge of nitrogen and phosphorous per person per day, as mentioned above. However catogories for type of treatments and treatment efficiencies differs somewhat. Therefore, treatment efficiencies for small wastewater treatment plants, in percentage, are specified below:

Type of treatment

Phosphorous

Nitrogen

Direct discharges

0

0

Sludge separator

5

5

Sludge separator with infiltration

75

20

Sludge separator with sand filter

15

15

Mini wwtp, biological

15

10

Mini wwtp, chemical or chemical-biological combined

90

15

Sealed tank*

100

100

Sealed tank for blackwater**

75

90

Biological toilet**

75

75

Constructed wetland**

90

50

Sealed tank for black water, filter for grey water**

90

90

Biological toilet, filter for grey water**

90

80

Other treatment***

50

20

* Wastewater from sealed tanks are normally delivered to other wastewater plants and treated elsewhere, thus, discharge and treatment efficiency calculations are included with them.

** Standard factor set up in collaboration with Bioforsk.

*** Standard factor set up in collaboration with Norsk Vann.

Calculation of discharges of organic material, heavy metals and persistant organic pollutants

The calculations are mainly built on the method suggested by Blytt og Storhaug (2008).

The method was originally designed for heavy metals and persistant organic pollutants, but it has now also been extended to cover also organic material (biological oxygen demand (BOD 5 ) and chemical oxygen demand (COD)). The statistics presented here covers only discharges from treated wastewater to the water recipient. In addition the statistics, so far, only covers discharges from wastewater treatment facilities 50 pe or larger.



The following parameters are included in the statistics:

- Arsenic (As)

- Cadmium (Cd)

- Crom (Cr)

- Copper (Cu)

- Mercury (Hg)

- Nickel (Ni)

- Lead (Pb)

- Zink (Zn)

- DEHP

- Biological oxygen demand (BOD 5)

- Chemical oxygen demand (COD)



A. Annual discharge from wastewater facilities reporting annual discharge data

Calculation of discharges from these wastewater facilities are relatively straight forward. The discharges constitute the total sum of calculated discharges from all these facilities (either reported as (1) kg discharge per year or (2) the combination of the volume of water treated and average concentration of the parameter).



According to the Pollution Regulation (nor. Forurensningsforskriften), chapter 11, wastewater treatment plants larger than 20 000 pe are required to do water sampling and analyse for content of heavy metals, while wastewater treatment plants larger than 50 000 pe in addition are required also to analyse for a selection of organic pollutants. That means large wastewater treatment plants directly or indirectly report actual discharge data which can be used for statistical purposes, while discharges from smaller treatment plants are largely unknown.



B. Annual discharge from wastewater treatment plants with no reported discharge data

Calculation of discharges which are not covered by the Pollution regulation, or for some other reason are missing, will be estimated for. The estimations are based on standard factors - discharge per person connected. The data source to establish these factors are based on actualy data from treatment plants in "point A" above. Data on people connected to wastewater facilities exist in most cases, even if they don't carry out analyses, and thus, this informatio is the used to upscale discharges to national level.



Thus, for every wastewater facility in "point A" above with reported discharge data, we will first calculate a specific discharge for each chemical component (unit: microgram / person connected):



Spesific discharge = microgram discharge per year / number of people connected



This is carried out on every wastewater facility containing actualy data for every component being analysed. Then these wastewater facilities are divided into two categories based on their type of treatment:

  • Treatment category I: direct discharges, mechanical and other treatment
  • Treatment category II: chemical, biological, chemical-biological and natural purification

For each of these treatment categories, the median value for each heavy metal and each organic pollutant will become the overall specific discharge factor. "People connected" in the sense applied here means permanent residents who are being served by the wastewater facility through their pipeline system.



For example cadmium, there will be two spesific discharge factors, one for treatment category I and another for treatment category II. The same applies to all the other components in the statistics. The factors are updated each year based on the most recent data reported.



Please note! For BOD 5 and COD, a 5 per cent trimmed average instead of median value has been used when establishing the spesific discharge factors. This deviates from the original method suggested by Blytt and Storhaug (2008). The reason for this adjustment in method is that this better explains the variation in discharges for these particular components. Spesific discharge factors for the different chemical components:

Component

Treatment category I

Treatment category II

Unit per person and year

Arsenic (As)

166 294 89 082

microgram

Cadmium (Cd)

9 518 4 968

microgram

Crom (Cr)

312 469 104 856

microgram

Copper (Cu)

3 476 703 907 270

microgram

Mercury (Hg)

3 565 717

microgram

Nickel (Ni)

615 857 489 071

microgram

Lead (Pb)

208 496 57 275

microgram

Zink (Zn)

9 556 035 4 503 730

microgram

DEHP

931 643 107 217

microgram

BOD5

18.68 3.40

kilogram

COD

32.94 10.97

kilogram

Source: `KOSTRA 2019-data (reported Spring 2020).

When the spesific factores have been established, they are then applied to the wastewater facilities with no discharge data (in point B). For example if a treatment facility belonging to treatment category I has 1 500 people connected, the estimated discharge is then 1 500 people multiplied with the discharge factor for treatment category I.



In this way, by partly using data based on actual analyses and partly by using estimations/factors, the statistics on heavy metals and organic pollutants, one can then calculate a national discharge for the whole wastewater sector.





Additional calculation and adjustments for BOD 5 and COD

For BOD 5 and COD there exist an additional calculation compared to what is the case with heavy metals and persistand organic pollutants. It only applies in those cases when it has been reported (1) data on BOD 5 , but not COD, or (2) data on COD, but not BOD 5 . Both BOD 5 and COD measure organic material, and in order to avoid too much estimations, discharges in these instances are calculated from a theoretical BOD 5 /COD-relationship (source: KOSTRA 2012-data):

  • Treatment category I: 0.50
  • Treatment category II: 0.26

For example the BOD 5 /COD-relationship in treatment category I of 0.50 means that the amount of BOD 5 in average is 50 per cent of what is the case with COD. The BOD 5 /COD-relationships above have been established based on wastewater facilities that reports both BOD 5 and COD, and thus makes it possible to establish a more general BOD 5 /COD-relationship. The relationship is then applied to those wastewater facilities that misses either BOD 5 or COD in their reporting (but not both!). For example if a wastewater facility belonging to treatment category II is reporting 200 tonnes of BOD 5 , but data on COD is missing in their reporting, then this facility will have an estimated COD discharge of 200 tonnes / 0.26 = 769 tonnes. Opposite, if a wastewater facility belonging to the same treatment category reports 200 tonnes of COD, then the BOD 5 discharge will be estimated to 200 tonnes * 0.26= 52 tonnes.

Consequently, discharge from these "one-sided" reportings (wastewater facilities) will be calculated based on part factor (BOD 5 /COD-relationship) and part discharge data and actual analyses (either BOD 5 or COD). This is considered a "second best solution" for estimating discharges for these facilities as apposed to a complete factor calculation.

Calculation of use of sewage sludge

The 2005-data-reporting introduced a new way of reporting sewage sludge compared to earlier years. Gross sewage sludge and its associated percentage dry weight are now included in the reporting compared to earlier it was only asked for dry weight of sewage sludge. In order to calculate the dry weight now, the information of percentage dry weight is essential. In cases where percentage dry weight is missing, then the following method has been applied to the data:



1. If percentage dry weight of the produced sludge product has been reported, but not for the amounts of sludge used, then this percentage has been applied.



2. If percentage dry weight of neither the produced sludge product nor the amounts used has been reported, a standard factor of 25 per cent dry weight has been applied.



Calculation of heavy metal content in sewage sludge

The calculation of average heavy metals in sewage sludge constitutes a weighted average of the reported figure; that is the content of heavy metals is weighted based on the amount of sludge reported for the different wastewater treatment plants. Thus, figures reported from larger treatment plants generally influence the final average figures more compared to smaller ones.



In the same way, maximum heavy metal content in sludge constitutes a weighted average figure of the values reported as maximum (as above, weighted against the amounts of sewage sludge disposed).

Calculation of number of small wastewater treatment plants (less than 50 pe) and their corresponding inhabitants connected.

Due to the fact that there is less reliable information available on smaller treatment plants, some estimation is necessary. Two estimation techniques may occasionally be applied:



1. Certain municipalities lack information on the distribution of inhabitants on type of treatment for smaller wastewater treatment plants. If the municipality has provided information on total amount of inhabitants connected, in addition to number of small treatment plants, the inhabitant distribution on type of treatment is estimated. The inhabitants are then distributed proportionally based on the number of treatment plants. For example lets say the municipality reports totally 3000 inhabitants connected to small treatment plants, 400 sludge separators, and 500 sludge separators with infiltration, but no distribution of inhabitants on types of treatment. Then the inhabitants connected is estimated to be 3 000x(400/(400+500)) = 1 333 inhabitants to sludge separator and 3 000x(500/(400+500)) = 1 667 inhabitants to sludge separators with infiltration, totally 3 000 inhabitants.



2. If the municipality lacks information on number of small treatment plants, but has information on the number of inhabitants connected, then this information may be used for estimation purposes. A theoretical connection factor based on the reported material is being applied. In 2019, this factor was 2.3 inhabitants per wastewater treatment plant (median value). For example if a municipality has the following information: 1 000 inhabitants connected to sludge separator, the estimated figure turns out to be 1 000/2,3 = 434 small treatment plants.

Economic data

Due to missing or incomplete data, estimates are made for some municipalities. This is done because figures for the entire country are to be estimated. For municipalities which do not report figures for operating expenditures and capital costs figures have been estimated. The estimates are based on the data from the municipalities that have reported data. The basis for the estimation is that there are a correlation between the variable and an explanatory variable (population in the municipality). The estimates for the individual municipality are not published.

Not relevant

Not relevant

In recent years, a few re-calculations has been carried out in the earlier published statistics. The reason is commonly due to correcting erroneous data in the times series. Note then that the last and current version of the statistics will always be found in Statbank.

For more details, see chapter 2.10 in the report Municipal wastewater: Expenditures, investment, municipal fees, discharges, treatment and disposal of sewage sludge.

The statistics of individual wastewater treatment plants (less than 50 pe) is often more uncertain compared to wastewater treatment plants equal ot or larger than 50 pe.

The data on heady metals and organic pollutions are also generally associated with high level of uncertainty (only lalrge wastewater facilities actually do sampling and analysis on this).

For more details, see chapter 2.9 in the report Municipal wastewater: Expenditures, investment, municipal fees, discharges, treatment and disposal of sewage sludge.

Statistics Norway carry out quality check on all the data - combination of manual and automatic. Priority is put on large deviations and the most commonly cheks are oulier detection and comparison to the preious years.
